Below you're find a high level process flow of how MINIBC interacts with the BigCommerce checkout as well as the renewal process. Should you have further technical questions you can always contact us and we'd be happy to speak further.
CHECKOUT
Get Payment Configuration and Payment Methods
1. Send request to retrieve checkout content.
2. Returns the current checkout content.
3. Sends request with checkout content.
4. Returns frontend payment configuration options.
Setup Payment Form
5. Sends frontend payment configuration to payment provider.
6. Returns configuration data and display payment provider frontend components.
Get Payment Request Token
7. Send request to retrieve checkout content.
8. Returns the current checkout content.
9. Sends request to MINIBC with order details.
10. Returns temporary payment token for this order.
Create Order
11. Sends request to convert checkout into a pending order.
12. Returns pending order details.
Make Payment
13. Sends request to payment provider to exchange card details for a temporary token.
14. Returns temporary nonce token.
15. Submits request to MINIBC with temporary nonce token.
16. Sends temporary nonce token and order details to payment provider for payment transaction.
17. Returns payment transaction results and a card reference token if applicable.
18. Sends request to update order based on the payment results.
19. Returns the updated order details.
20. Returns the payment result and redirect user to order confirmation page.
21. Retrieve final order details.
22. Returns the order details.
23. Create subscription based on the order details.
RENEWAL
Create Order
1. Sends request to create a pending order.
2. Returns pending order details.
Make Payment
3. Submits payment request using the card reference token and order details.
4. Returns payment transaction results.
5. Sends request to update order based on the payment results.
6. Returns the updated order details.
